Residual Current Molded Case Circuit Breaker

Factory-direct Residual Current Molded Case Circuit Breaker wholesale – 50% off bulk orders. Molded case circuit breakers operate on the principle of thermal release contacts. When the current exceeds the rated value, the contacts heat up, causing the spring force to decrease, ultimately disengaging the contacts and cutting off the power supply.

Residual Current Molded Case Circuit Breaker is suitable for household, commercial, and industrial electrical systems, and is commonly used to protect AC power lines and terminal equipment, such as distribution boxes, air conditioners, lighting equipment, and motors. Furthermore, molded case circuit breakers can also be used for circuit protection in high-temperature, humid, and explosive environments.

Note: If you have any puzzles or requests about this product (including model number, data sheet or any other aspects), please contact us immediately.

Operating Environment

1. Ambient air temperature: -5℃～+40℃

2. Installation site altitude not exceeding 2000 meters

3. Relative humidity at the installation site should not exceed 50% at the highest temperature of +40℃. Higher relative humidity is permissible at lower temperatures, for example, up to 90% at 20℃. Special measures should be taken for occasional condensation caused by temperature changes.

4. Pollution degree: Level 3

5. Residual Current Molded Case Circuit Breaker meets the testing requirements of GB/T2423.4 and GB/T2423.18, and can withstand the effects of humid air, salt spray, oil mist, mold, etc.

6. The Residual Current Molded Case Circuit Breaker should be installed in a location free from explosion hazards and conductive dust (insufficient to corrode metal and damage insulation).

7. The circuit breaker should be installed in a location protected from rain and snow intrusion.

8. Operating conditions: The circuit breaker meets the test requirements of GB/T 2423.1 and GB/T 2423.2. The ambient air temperature can be as low as -25℃ (ARM1DC/ARM3DC/ARM6DC can provide temperatures as low as -40℃, please consult our company), and the maximum can reach +70℃ (the capacity will decrease when the temperature exceeds 40℃, please refer to the technical data of the attached sample).

Application

* In medium and low voltage power systems

* Protect circuits from overload, short circuit,s and other faults

* In the industrial control system

* Protect motors, transformers, and other equipment

* Used in household, commercial, and industrial building electrical

* Used to protect communication equipment, communication lines, etc.

* Electrical system of new energy equipment such as solar energy and wind energy

* Guarantee the safe operation of electrical equipment
